(design no. 48a) Locomotion
| Specs | |||
|---|---|---|---|
| keel type: lifting |
hull: composite |
hull section: round bilge |
rig type: |
| pilot house : cubby seats |
head room: 2.03 m |
# berths: 5 |
# heads: 1 |
| Dimensions | |||
|
length: 11.60 m |
loa: 11.79 m |
lwl: 11.00 m |
beam: 3.77 m |
| draft: 1.35 - 2.83 m |
displacement: 4.96 t |
ballast: 2220 kg. |
|
| Sails & Rig | |||
| sail area: 85.88 m 2 | E : 5.25 m | P : 17.85 m | I : 14.85 m |
| J : 3.50 m | |||
| Engine | |||
| Lombardini LDW 1003M | |||
